| Cabo DisplayPort 1.2 HD - 10.0m
From the Lines cable connectivity concept developed by Lindy, Anthra Line DisplayPort cables are the professional choice for high performance connections in commercial AV and IT installations.
- Professional choice DisplayPort 1.2 cable for commercial and high performance AV and IT installations
- Supports UHD resolutions up to 4096x2160@60Hz 4:4:4 10bit
- Robust ABS housing 24K gold plated connectors and contacts
- Triple shielded cable, corrosion resistant tinned copper 28AWG conductors
- DisplayPort 1.2, 4K, 3D, 21.6Gbps
From the Lines cable connectivity concept developed by Lindy, Anthra Line DisplayPort cables are the professional choice for high performance connections in commercial AV and IT installations.
Anthra Line DisplayPort cables are premium connections that feature triple shielded with 26AWG tinned copper conductors for performance and corrosion resistance. High quality gold plated contacts and connectors maintain optimal signal integrity and maximum reliability.
UHD resolutions up to 4K 4096x2160@60Hz 4:4:4 10bit, including stereoscopic 3D and HDCP are supported. DisplayPort 1.2 technology ensures compatibility with all DisplayPort enabled devices.
Technical details - Connectors
- Connector A: DisplayPort Male
- Connector B: DisplayPort Male
- Housing Material: ABS
- Connector Plating: 24K Gold 15µm
- Pin Construction: Copper Alloy
- Pin Plating: Gold
- Dimensions (approx.) WxDxH: 20.4x36.0x12.7mm (0.8x1.42x0.5in)
- Cable Construction
- Length: 10.00m
- Standard: DisplayPort 1.2
- Colour: Black
- Type: Round
- Jack Diameter: 8.5mm (0.34in)
- Jacket Material: PVC
- Conductor Material: Copper
- Conductor Gauge: 26AWG
- Shielding: Copper Braid 50%
- Specifications
- Supported Bandwidth: 21.6Gbit/s
- Maximum Resolution:
- 4096x2160@60Hz 4:4:4 10bit
- Nominal Attenuation: 100MHz - 450MHz > -2.44dB , 450MHz - 8100MHZ > -5.094dB
- Minumum Band Radius: 85mm (3.35in)
- Operating Temperature: -10°C - 80°C (14°F - 176°F)
- Storage Temperature: -25°C - 85°C (-13°F - 185°F)
- Miscellaneous
- Packaging Type: Polybag
- Certificated: RoHS, REACH, UL
