| 1.0m USB4 Type C Cable, 40Gbps, 240W PD, Black Line
Type C Male to C Male
- Blazing-fast data transfer speeds up to 40Gbps, perfect for ultra-fast file transfers, rapid backups and seamless high-resolution media streaming in demanding professional workflows.
- Delivers up to 240W of power via USB Power Delivery (48V 5A) to rapidly charge laptops, tablets, and smartphones, keeping devices powered throughout demanding workdays.
- Supports video at up to 8K 60Hz via DisplayPort Alternate Mode, enabling ultra high-resolution video output for modern laptops, workstations, and AV systems.
- Triple-shielding for enhanced signal integrity and nickel-plated connectors for durable, corrosion-resistant performance.


Connectors
The Black Line USB 4 Gen 3x2 Type C, 240W PD cables from Lindy are designed for everyday use in home and small office environments. Part of Lindy´s entry-level Cable Lines range, they are built using standard, high-quality materials to ensure reliable performance for daily tasks.
An integrated E-Mark chip enables safer 240W (48V 5A) fast charging with USB Power Delivery, allowing for the voltage and current to be automatically adjusted to the needs of connected such as mobile phones, tablets and laptops to prevent overvoltage and overcurrent.
USB 4 Gen 3x2 delivers high-speed 40Gbps transfer speeds, doubling the performance of previous USB generations. Whether you're transferring massive design files, editing high-resolution videos directly from external storage, or connecting next-gen peripherals, this standard ensures maximum efficiency and zero bottlenecks.
DisplayPort Alternate Mode enables crisp dual 4K or single 8K video output at 60Hz, making them perfect for connecting to ultra-high-resolution displays and AV equipment. The robust triple-shielded design with tinned copper conductors and nickel-plated connectors delivers reliable signal quality and solid protection against EMI/RFI in everyday and office environments.
With reversible USB Type C connectors and full bi-directional communication, these cables guarantee simple, reliable connections every time.
Connectors - Connector A: USB4 Type C Male
- Connector B: USB4 Type C Male
- Housing Material: PVC
- Shielding in head shell: -
- Connector Plating: Nickel
- Pin Construction: Copper
- Pin Plating: Gold
- Dimensions (approx.) WxDxH: 34.8x12.7x7.4mm (1.37x0.5x0.29in)
Cable Construction - Jacket Diameter: 4.5mm (0.18in)
- Jacket Material: PVC
- Conductor Material: Copper
- Conductor Gauge Power: 24AWG
- Conductor Gauge Data: 32AWG
- Shielding: Aluminium Foil + 60% Braiding
Specifications - Length: 1.5m (3.28ft)
- Colour: Black
- Type: Round
- Standard: USB4 Gen 3x2
- Supported Bandwidth: 40Gbps
- Maximum Power: PD 3.1 with EPR up to 240W (48V 5A)
- E-Mark: Yes
- Maximum Resolution: 3840x2160@60Hz, 7680x4320@60Hz
- Supported Procotols: USB4, USB 3.2, USB 2.0, Thunderbolt 3, DisplayPort 2.0
- Nominal Attenuation: -12. 2dB@5G, -18.3dB@10G
- Minimum Bend Radius: 20mm (0.79in)
- Operating Temperature: 0°C - 40°C (32°F - 104°F)
- Storage Temperature: -10°C - 60°C (14°F - 140°F)
Miscellaneous - Packaging Type: Polybag
Product Compliance: RoHS, REACH, California Proposition 65
This product is also available in other lengths - 37000 - 0.5m (1.64ft)
- 37001 - 1m (3.28ft)
- 37002 - 2m (6.56ft)
|
