The Lindy VGA & Audio to HDMI Converter combines analogue video and stereo audio signals and converts them into a HDMI signal, perfect for using legacy PC and AV equipment with HDMI displays. It supports resolutions up to 1920x1080. The integrated USB cable can be connected to a USB port or USB power supply to power the converter.
- Converts and combines VGA video and analogue audio signals into a HDMI signal
- Supports resolutions up to 1920x1080@60Hz
- Perfect for connecting older VGA computers to a HDMI display
- Powered by USB, simple plug and play installation
The converter is also ideally suited for travelling due to its compact, lightweight form factor and convenient Plug & Play installation.
Technical Information - Specifications
- AV Interface: VGA & Audio to HDMI
- Interface Standard: HDMI 1.3, VGA
- Supported Bandwidth: 4.95Gbps
- Maximum Input Resolution: 1920x1080@60Hz
- Maximum Output Resolution: 1920x1080@60Hz
- Chipset: AG02EX
- HDCP Support: -
- Supported Audio: Stereo Audio
- Separate Audio Ports: -
- Special Features: Powered by USB port
- Connectors
- Input: VGA Male, 3.5mm Stereo Audio , USB Type A Male (for power)
- Output: HDMI Type A Female, 3.5mm Audio
- Physical properties
- Dimensions (approx.) WxDxH: 45x45x16mm (1.77x1.77x0.63in)
- Cable Length: VGA cable: 140mm (5.51in), USB cable: 600mm (23.62in), Audio cable: 565mm (22.24in)
- Housing Material:
- VGA/USB/Audio: PVC
- HDMI: ABS
- Jacket Material: PVC
- Jacket Diameter:
- VGA: 5.5mm (0.22in)
- Audio: 3mm (0.12in)
- USB: 3mm (0.12in)
- Minimum Bend Radius: -
- Net Weight: 0.081g (0.18lb)
- Operating Temperature: 0°C - 70°C (32°F - 158°F)
- Storage Temperature: 0°C - 60°C (32°F - 140°F)
- Humidity: 10 - 85% RH (non-condensing)
- Colour: Black
- Miscellaneous
- Packaging Type: Polybag
- Packaging Dimensions: 176x194mm (6.93x7.64in)
- Gross Weight: 0.12kg (0.26lb)
- Certificated: CE, FCC, RoHS & REACH, CP65
- Package Contents
- VGA & Audio to HDMI Converter
- Lindy Manual
|
